10KVA TVR Relay Stabilizer 90v – 280V
15KVA Relay Voltage Stabilizer (45V-250V)
CODE= AERB45-W-15KVA
PRODUCTS SPECIFICATION
MODEL: AERB45-W-15KVA INPUT VOLTAGE: AC 45V-280V< OUTPUT VOITAGE: AC220V±10% 50/60HZ DELAY TIME: Short Delay:3-5sec, Long Deley:3-7min PROTECTION: Over Voltage(246V±4V), Overload,High Temperature,Short Circuit POWER: 15000VA PRODUCT SIZE(CM) PACKING SIZE(CM): 51.8*38.5*24PCS/CARTON1N.W.(KGS) G.W.(KGS)25.2
20KVA Relay Desktop Voltage Stabilizer (95V-270V)
PRODUCTS SPECIFICATION
| MODEL | AERB95-D-20KVA |
| INPUT VOLTAGE | AC 95V-270V |
| OUTPUT VOITAGE | AC220V±10% 50/60HZ |
| DELAY TIME | Short Delay:3-5sec Long Deley:3-7min |
| PROTECTION | Over Voltage(246V±4V),Overload,High Temperature,Short Circuit |
| POWER | 20000VA |
| PRODUCT SIZE(CM) | |
| PACKING SIZE(CM) | 50*46*58.7 |
| PCS/CARTON | 1 |
| N.W.(KGS) | |
| G.W.(KGS) | 58 |
20KVA Relay Voltage Stabilizer (95V-270V) (AERB95-W-20KVA)
PRODUCTS SPECIFICATION
| MODEL | AERB95-W-20KVA |
| INPUT VOLTAGE | AC 95V-270V |
| OUTPUT VOITAGE | AC220V±10% 50/60HZ |
| DELAY TIME | Short Delay:3-5sec Long Deley:3-7min |
| PROTECTION | Over Voltage(246V±4V),Overload,High Temperature,Short Circuit |
| POWER | 10000VA |
| PRODUCT SIZE(CM) | |
| PACKING SIZE(CM) | 51.8*38.5*24 |
| PCS/CARTON | 1 |
| N.W.(KGS) | |
| G.W.(KGS) | 23.2 |
30KVA Relay Voltage Stabilizer (95V-270V)
PRODUCTS SPECIFICATION
| MODEL | AERB95-D-30KVA |
| INPUT VOLTAGE | AC 95V-270V |
| OUTPUT VOITAGE | AC220V±10% 50/60HZ |
| DELAY TIME | Short Delay:3-5sec Long Deley:3-7min |
| PROTECTION | Over Voltage(246V±4V),Overload,High Temperature,Short Circuit |
| POWER | 30000VA |
| PRODUCT SIZE(CM) | |
| PACKING SIZE(CM) | 50*46*58.7 |
| PCS/CARTON | 1 |
| N.W.(KGS) | |
| G.W.(KGS) | 58 |
AE Dunamis 10KVA Relay Stabilizer TVR-10000VA
| SPECIFICATION RELAY TYPE | |||||||
| Product | Technology | TVR-10000VA | |||||
| Power (VA) | |||||||
| Input | Phase | Single phase | |||||
| Voltage (6) | AC 80V-260V | ||||||
| Frequency | Â 50Hz/60Hz | ||||||
| Output | Voltage Range | AC220V | |||||
| Precision | ±10% | ||||||
| Frequency (Inverter Mode) | Â 50Hz/60Hz | ||||||
| Power factor | 100% ALUMINUM (Round) | ||||||
| Function | Control type | relay | |||||
| Over/Low Volt protection | yes | ||||||
| Circuit Protection | yes | ||||||
| Digital display | Â Show input and output voltage | ||||||
| Delaying | 6 Secs(short)/ 180 Secs(long) | ||||||
| Short Circuit & Over Load | MCB | ||||||
| Transfromer | Material | 100% ALUMINUM (Round) | |||||
| Efficiency | AC-AC | 0.96 | |||||
| Acoustic | Noise level | ≤50dB | |||||
| Environment | Temperature | Â -5-60 DegreeC | |||||
| Humidity | 20% to 90% | ||||||
